| Specification |
Details |
| Welder Type |
HF TIG, Lift TIG, Stick Multi-Process Inverter |
| Number of Phases |
Single Phase |
| Nominal Supply Voltage |
220 VAC ± 15% |
| Nominal Supply Frequency |
50/60 Hz |
| Welding Current Range – TIG |
10 – 250 A |
| Welding Current Range – Stick |
10 – 250 A |
| Nominal DC Open Circuit Voltage |
75 V |
| Factory Fitted Supply Plug Rating |
15 Amps |
| Effective Input Current (I1eff) |
15 Amps |
| Maximum Input Current (I1max) |
33.9 Amps |
| Minimum Single Phase Generator Recommendation |
9.5 kVA at 0.8 PF |
| STICK (MMAW) Welding Output, 40ºC, 10 min. |
250 Amps @ 20% Duty Cycle |
| TIG (GTAW) Welding Output, 40ºC, 10 min. |
300 Amps @ 30% Duty Cycle |
| Protection Class |
IP21S |
| Cooling |
Fan Cooled |
| Power Source Mass |
7.8 Kg |
| Power Source Dimensions (H x W x D) |
245 mm x 145 mm x 390 mm |
| Standards of Conformity |
IEC 60974-1 |
