ZYROD 300 TIG WELDING MACHINE
The ZYROD300 is a single-phase welding inverter tailored for Indian standards, operating at 220V. With user-friendly controls, advanced features, and robust construction, it is ideal for light TIG fabrication and stainless steel welding. Designed for portability and high performance, it is perfect for tradespeople and maintenance workers
Key Features
- 220V Operation:
- Inverter-based machine designed for Indian mains supply.
- Current Range:
- TIG (10-300A), Stick (10-250A).
- Advanced Controls:
- HF Start for non-contact TIG welding.
- Arc Force, Hot Start, and Anti-Stick for smooth and efficient operation.
- Portable Design:
- Lightweight at 8.2 kg, with a carry handle for easy transport.
- Durable Build:
- Rugged case with over-temperature cut-out protection.
- Multipurpose Functionality:
- Perfect for TIG and Stick welding across various applications.
- Efficient Power Use:
- Minimum generator recommendation of 9.5 kVA ensures compatibility with local setups.
Technical Specifications
| Specification | KOKO-TAWA ZYROD-300 |
|---|---|
| Welder Type | HF TIG, Lift TIG, and Stick Multi-Process Inverter |
| Number of Phases | Single Phase |
| Nominal Supply Voltage | 220 VAC ± 15% |
| Nominal Supply Frequency | 50/60 Hz |
| Welding Current Range - TIG | 10 - 300 A |
| Welding Current Range - Stick | 10 - 250 A |
| Nominal DC Open Circuit Voltage | 75 V |
| Factory Fitted Supply Plug Rating | 15 Amps |
| Effective Input Current (I1eff) | 15 Amps |
| Maximum Input Current (I1max) | 33.9 Amps |
| Minimum Single Phase Generator Recommendation | 9.5 kVA at 0.8 PF |
| STICK (MMAW) Welding Output, 40ºC, 10 min. | 250 Amps @ 20% Duty Cycle |
| TIG (GTAW) Welding Output, 40ºC, 10 min. | 300 Amps @ 30% Duty Cycle |
| Protection Class | IP21S |
| Cooling | Fan Cooled |
| Power Source Mass | 8.2 Kg |
| Power Source Dimensions (H x W x D) | 245 mm x 145 mm x 420 mm |
| Standards of Conformity | IEC 60974-1 |
Application
- Light TIG fabrication.
- Stainless steel welding.
- Maintenance and repair work.
- Workshop and on-site projects.
Package Includes
- Power Source : ZYROD 300i TIG Welding Machine.
- TIG Torch : Options for Water Cooled / Gas Cooled.
- Argon Gas Regulator with Flow Meter..
- Hose Pipe : 2mtr with clamp.
- Welding Helmet : Optional.
- Earthing Cable with Clamp : 2mtr.
- Welding Cable with Holder : 2mtr (Optional).
